Ideal for applications where keeping clippings off
sidewalks, driveways and parking lots is vital, the
Grasshopper 4X Rear Discharge™ deck offers revolutionary
performance, utilizing less horsepower to significantly
reduce fuel costs and increasing mowing flexibility.
The deck’s unique four-spindle design evenly distributes
clippings through the back of the deck, eliminating
windrowing and helping to reduce material buildup in
the engine compartment for cleaner operation. Well suited
for use in cemeteries, the 4X Rear Discharge™ deck
allows trimming around stones on either side of the
deck, while the rear discharge design won’t leave
clippings on the stones.
Available in 52-, 61- and 72-inch cutting widths.
The four-spindle design spreads the load of clippings
and debris and channels it through the rear of the
deck.
Rear discharge allows operators to trim on either side of the deck, reducing hand trimming and eliminating time-consuming blowing after mowing.
Sentry™ spindle design with 8-inch spindle housing, 6-bolt pattern and Sentry™ cone guards protect the spindle shaft from material wrap.
Anvil-edged deck with 1/2-inch-thick formed steel leading edge features 7-gauge skirts and geometrically engineered design for superior impact protection that will withstand the punishments of commercial mowing.
Lower horsepower requirements are a perfect complement to Grasshopper MaxTorque™ diesel units to maximize fuel savings.
An ideal match for Grasshopper’s Edge-EZE™
edger. The edger can be mounted on either side of
the deck for enhanced flexibility
The rear discharge decks are perfect for government and municipal contracts, especially for roadways. They keep the clippings off the road and let us edge from either side.
